DATA SHEET PART NO. : L-C170KGCT REV : A/0 CUSTOMER S APPROVAL : DCC : DRAWING NO. : DS-72-03-0005 DATE : 2003-12-12 PAGE 1 of 11 PARA-FOR-065 SURFACE MOUNT DEVICE LED Part No. : L-C170KGCT REV:A / 0 PACKAGE OUTLINE DIMENSIONS BACK VIEW TOP VIEW 1.05 1.25 SIDE VIEW MOLDING BODY (LENS) P.C BOARD R0.10 0.45 POLARITY LED DICE SOLDERING TERMINAL CATHODE 2.00 + 1.50 REF. 0.95 0.45 5.00 0.80 0.28 0.30 0.35 Notes: 1. All dimensions are in mill.
